How To Find A Replacement Cartridge Filter Element

How To Find

1. Identify your existing Cartridge Filter Element by brand and/or model number then use these details to search our Replacement Cartridge Filter Element Product List containing our most popular and universal model numbers.

2. If you cannot identify your Cartridge Filter Element by brand and/or model number measure the existing Cartridge Filter Element and search our Replacement Cartridge Filter Element Product List by dimensions. Follow the steps below to measure your Cartridge Filter Element.


Measuring Your Cartridge Filter Element

Replacement Cartridge Filter Element Cutaway Diagram
STEP 1:  Measure the outside diameter of your Cartridge Filter Element (in inches, within 1/32").

STEP 2:  Measure the Cartridge Filter Element's length (in inches, within 1/16") including end caps but excluding any handles or other extensions. Unicel recommends measuring through the center (if possible) rather than along the outside edge.

STEP 3:  Identify the Cartridge Filter Element's outside edge End Cap Configuration.

CLICK HERE TO VIEW END CAP CONFIGURATION DESIGN

If the top and/or bottom is "open," measure the inside diameter (in inches, within 1/32") of the top and/or bottom.

STEP 4:  Count the number of pleats (within 2), and note whether there is a center core or not.

The information gathered in Steps 1-4 (above) can now be used to identify a proper Replacement Cartridge Filter Elelment.


If you still cannot identify your Cartridge Filter Element, click on the links below to help narrow your search:

CLICK HERE TO SEARCH UNICEL REPLACEMENT CARTRIDGES BY “SERIES” BASED ON THE OUTSIDE DIAMETER (O.D.) OF THE CARTRIDGE

Unicel Replacement Cartridge Filter Elements are grouped into series based on the approximate outside diameter (O.D.) of the cartridge. For example, the 2000 Series is comprised of Cartridge Filter Elements between 2 and 2.99 inches in outer diameter; the 9000 Series is comprised of Cartridge Filter Elements with an outer diameter of 9 inches or greater.

Note that if the Cartridge Filter Element's length is either 4-15/16 or 6-15/16 it may be necessary to check the next larger series, the 5000 Series and 7000 Series, respectively. Within each series, Cartridge Filter Elements are listed sequentially by O.D. and length and identified according to end cap I.D. (inside diameter) and configuration, pleat count, and respective Original Equipment Manufacturer.

CLICK HERE TO CROSS REFERENCE BY ORIGINAL EQUIPMENT MANUFACTURER (O.E.M.) OR BRAND NAME
CLICK HERE TO SEARCH BY UNICEL REPLACEMENT CARTRIDGE PART NUMBER
CLICK HERE TO SEARCH INFORMATION FOR D.E. CARTRIDGE FILTER ELEMENTS (BY SIZE, O.D. & O.E.M.)
CLICK HERE FOR GLOSSARY OF TERMS, ADDITIONAL CLEANING INSTRUCTIONS AND HELPFUL TIPS

OR

CONTACT US with your measurements and any other details you may have and we will locate the Replacement Cartridge Filter Element that you are looking for.
